Elevator bucket Type BE
Elevator bucket type BE
This durable medium-deep elevator bucket type BE has a large volume and considerable projection. This gives the BE elevator bucket a high capacity.
The plastic BE elevator buckets are available in HDPE and nylon.
| BE type plastic elevator buckets (parameters in mm) | BE type plastic elevator buckets (parameters in mm) | |||||||||||
| Type | Size/weight | Volume (L) | Holes | Max | ||||||||
| b | a | h1 | h2 | t | Kg | Z2 | Z3 | d | e | Nr | Buckets/m | |
| BE130 x 120 | 138 | 120 | 91 | 59 | 3.9 | 0.104 | 0.8 | 0.61 | 7 | 60 | 2 | 8 |
| BE190 x 140 | 190 | 145 | 115 | 66 | 5.8 | 0.285 | 1.6 | 1.2 | 9 | 100 | 2 | 6 |
| BE230 x 140 | 235 | 140 | 110 | 78 | 6.5 | 0.335 | 1.9 | 1.49 | 9 | 120 | 2 | 6 |
| BE240 x 170 | 248 | 178 | 120 | 82 | 7 | 0.48 | 2.6 | 2.18 | 9 | 120 | 2 | 7 |
| BE260 x 160 | 260 | 167 | 144 | 56 | 6 | 0.51 | 2.2 | 1.25 | 9 | 80 | 3 | 7 |
| BE280 x 140 | 286 | 140 | 103 | 50 | 6 | 0.373 | 2.05 | 1.32 | 9 | 90 | 3 | 8 |
| BE280 x 160 | 290 | 167 | 108 | 55 | 6 | 0.44 | 2.5 | 1.38 | 9 | 90 | 3 | 8 |
| BE280 x 170 | 290 | 178 | 120 | 78 | 6 | 0.46 | 3.35 | 2.5 | 9 | 90 | 3 | 7 |
| BE280 x 240 | 289 | 244 | 166 | 120 | 6 | 1.02 | 6.4 | 5.6 | 9 | 100 | 3 | 4 |
| BE330 x 250 | 339 | 259 | 170 | 110 | 7.5 | 1.16 | 8.5 | 6.55 | 9 | 85 | 4 | 5 |
| BE380 x 230 | 382 | 230 | 165 | 110 | 7.6 | 1.12 | 8 | 6 | 9 | 100 | 4 | 5 |
| BE390 x 170 | 393 | 170 | 130 | 80 | 7 | 0.75 | 5 | 3.25 | 9 | 100 | 4 | 6 |
| BE440 x 230 | 447 | 230 | 165 | 110 | 8.7 | 1.455 | 9.2 | 7.3 | 9 | 90 | 5 | 5 |
| BE470 x 230 | 475 | 230 | 164 | 110 | 8.3 | 1.405 | 10 | 8.1 | 9 | 95 | 5 | 5 |
| BE470 x 260 | 470 | 260 | 170 | 113 | 9.5 | 1.71 | 11.5 | 9.4 | 9 | 95 | 5 | 5 |
| BE560 x 260 | 569 | 260 | 170 | 114 | 8.5 | 1.97 | 15 | 11.75 | 11 | 115 | 5 | 5 |
- Z2 = gross volume in liters, Z3 = net volume in liters.
These elevator buckets have no holes, but those may be drilled according to the client’s specifications.
